Size & weight
- Net weight 18.50 kg (40.8 lbs)
-
Dimensions
Height: 165mm (6.5in) cabinet only
233mm (9.2in) including tweeter
Width: 628mm (24.7in) cabinet only
Depth: 318mm (12.5in) cabinet only
356mm (14.0in) including grille and terminals
Technical details
-
Drive units
1x ø25mm (1in) Decoupled Carbon Dome high-frequency
1x ø130mm (5in) Continuum cone FST midrange
2x ø130mm (5in) Aerofoil Profile bass - Frequency range -6dB 45Hz - 33kHz
- Frequency response 50Hz - 28kHz ±3dB
-
Harmonic distortion
2nd and 3rd harmonics (90dB, 1m on axis)
<1% 90Hz - 22kHz
<0.5% 120Hz - 20kHz
- Nominal impedance 8Ω (minimum 3.1Ω)
- Recommended amplifier power 30W - 200W into 8Ω on unclipped programme
- Sensitivity 89dB spl (2.83Vrms, 1m)
-
Technical features
Decoupled Carbon Dome tweeter
Solid Body Tweeter-on-Top
Continuum™ cone FST™ midrange
Aerofoil™ Profile bass cones
Flowport™ - Description 3-way vented-box system
- Max recommended cable impedance 0.1Ω
Finishes
-
Cabinet finishes
Datuk Gloss
Midnight Blue Metallic
-
Grille finishes
Black
