Features
- Number of Channels 5
- THX No
- DTS No
- Dolby No
- DSD (SA-CD)/Neural No
- SRS No
- HDCD Decoder No
- Current Feedback Topology Yes
- Discrete Amplification Yes
- Power Transformer Large Capacity EI
- D/A Conversion No
- Digital Signal Processing No
- Video Off (Pure Direct) No
- Source Direct No
- Source Direct Steel
- Variable X-over Steel
- Display Off Blue LED Illumination off mode available
- Video Up-conversion No
- Auto Calibration by MIC No
- Satellite Radio Ready No
- AM/FM Tuner No
- Bass Redirection No
- Lip-sync (digital audio delay) No
- Software Upgradable No
In Outputs
- HDMI In No
- Component In No
- S-Video In No
- Composite In No
- HDMI Out No
- Component Out No
- S-Video Out No
- Composite Out No
- Analog L&R In No
- Analog L&R Out No
- Digital Optical In No
- Digital Coaxial In No
- Digital Optical Out No
- Digital Coaxial Out No
- Other No
- Pre-Amplifier Out No
- Main Amplifier In Balanced & Unbalanced: 5ch (Exclusive use by a selector switch.)
- Multi-Channel In No
- Multi-Room Audio Out No
- Multi-Room Video Out No
- Multi-Room Speaker Out No
- Speaker A/B No
- Networking No
- External control No
- DC Triggers 1 In / 1 Out
- D-Bus Remote (RC-5) In/Out 1 - 1
- Flasher In/IR Receiver In/Emitter out 1/0/0
- Front Panel A/V Inputs No
- Headphone Out No
- AC Outlets (Switched/Unswitched) No
Specifications
- Power Output 140W (20Hz-20kHz, 0.08%)
- S/N Ratio 105dB
- Freq. Response (Analog In) 8Hz-100kHz (+/- 3dB)
- Freq. Response (Dig In) No
- Frequency Range No
- S/N Ratio (Mono/Stereo) No
- Frequency Range No
- S/N Ratio No
- Video Freq. Response (Component) No
- Video Freq. Response (Composit, S-Video) No
- Signal to Noise No
General
- Color Black
- Front Panel Aluminum/Glass-reinforced resin
- Remote Control No
- Power Requirement No
- Power Consumption 660W (Standby: 0.2W)
- Dimensions W x H x D (Inchs) 17-3/8 x 7-3/16 x 15-1/8
- Weight (lbs) 34.6
