Features
- DAC operation mode: USB / Coax / Optical Yes / Yes / Yes
- Asynchronous mode rear USB Yes
- Bit-perfect transmission Yes
- USB-B DSD Audio Streaming: DSD2.8 / DSD5.6 / DSD11.2 Yes / Yes / Yes
- Ground isolator for DAC Mode operation Yes
- iPod / iPhone compatible USB input Yes
- DAC chip SABRE ES9010K2M
- HDAM version HDAM SA2
- High Grade Audio Components Yes
- Customized Components Yes
Inputs Outputs
- Headphone Out Yes
- Headphone Volume Control Yes
- Headphone Gain Control (low / mid / high) Yes
- Analog Input 2
- Digital Optical In / Out 2 / No
- Digital Coaxial In / Out 1 / No
- Sample Rate digital In 192kHz/24bit
- Number of Speaker Terminals 2x Marantz SPKT-1
- Gold Plated Cinch Yes
- Front USB Yes
- USB type B input for Computer (back) Yes
- Asynchronous mode rear USB Yes
- Sample Rate USB type B In 384kHz/32bit
- USB-B DSD Audio Streaming: DSD2.8 / DSD5.6 / DSD11.2 Yes / Yes / Yes
- D-Bus Yes
Others
- Power Output (8 / 4 Ohm RMS) 35W / 70W
- Frequency Response 20 Hz-50 kHz
- Signal to Noise Ratio 105 dB
- Total Harmonic Distortion 0,05%
General
- Available Colors Black
- Remote Control RC002HD
- Power Consumption in W 55
- Standby Consumption in W 0.3
- Auto Power off Yes
- Detachable Power Cable Yes
- Maximum Dimensions (W x D x H) in inches 12.0 x 13.9 x 4.2
- Weight in lbs. 12.8
