Eigenschappen
- Network Audio Streaming Yes
- Spotify Connect* / Tidal* / Deezer* / others * Yes / Yes / Yes / Yes
- Amazon Prime Music* / Pandora* Yes / Yes
- AirPlay 2 Yes
- Roon Tested Yes
- Internet radio TuneIn
- HEOS Multiroom and Streaming Yes
- Voice Control - Works with Amazon Alexa Yes
- Voice Control - Microphone built-in -
- CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC Yes / Yes / - / Yes / Yes / -
- CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data - / - / Yes / Yes / -
- Data Disc Compatibility: DSD / WAV / ALAC - / - / -
- USB input for memory stick Yes
- DAC Master Clock Design Yes
- DAC operation mode: USB-B / Coax / Optical Yes / Yes / Yes
- Asynchronous mode rear USB-B Yes
- Bit-perfect transmission Yes
- USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 / DSD11.2 Yes / Yes / Yes
- Signal isolator for DAC Mode operation Yes
- HDAM version HDAM + HDAM SA2
- Power Transformer: Toroidal / El Yes / -
- High Grade Audio Components Yes
- Customised Components Yes
- Symmetric circuit layout Yes
- Extra metal plate for chassis strengthing Yes (double layer, 1mm x 2)
- Digital out off / Audio EX Mode Yes / -
- Headphone: Standard / Buffer / Current feedback - / - / Yes (HDAM SA2)
Netwerk
- Wi-Fi / Wired LAN 2.4 GHz, 5 GHz / Yes
- Wi-Fi on / off mode Yes
- Bluetooth on / off mode Yes
- DSD Audio Streaming Up to DSD11.2MHz
- Lossy formats: MP3 / WMA / AAC Yes / Yes / Yes
- Lossless formats: DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24 Yes / Yes / Yes / Yes
- Gapless Playback Yes (FLAC, WAV, DSD)
- Remote APP: iDevice / Android Yes / Yes
- App control AMP/CD via Network Player Yes
Overige
- Selectable filter: CD / SA-CD / DAC-Mode Yes / - / Yes (PCM Only)
- Separated rectifier circuit for analogue and digital circuitry Yes
- Display: Dimmer / Off Yes / Yes
- Display 3 line OLED
Weergave
- Program Play (CD / SA-CD) 25 / -
- Repeat Yes
- Random Play Yes
Ingangen en uitgangen
- Analogue Out (RCA) 1
- Variable Out (RCA) 1
- Balanced Out -
- HDMI: ARC input for TV Yes
- Digital Optical In / Out 1 / 1
- Digital Coaxial In / Out 1 / 1
- Sample Rate digital In 192 kHz / 24-bit
- Gold Plated Cinch Yes
- USB Audio rear
- USB type B input for PC (rear) Yes
- Sample Rate USB type B In up to DSD11.2 kHz
- D-Bus Yes
- Remote Control Bus in / out -
- Headphone Out Yes
- Headphone Volume Control Yes
- Bluetooth / Bluetooth HP transmission Yes / Yes (Update)
- Ethernet port Yes
- IP control Yes
- Flasher Input Yes
- RS232 Yes
Specificaties
- Digital Filter Filter 1,2 selectable
- Noise Shaper None
- Low Pass Filter stage HDAM
- Output Buffer HDAM SA2
- Headphone amp HDAM SA2
-
Frequency Response
USB DSD 2Hz - 50kHz (-3dB)
USB PCM 2Hz - 50kHz (-3dB)
CD 2Hz - 20kHz (±1dB) -
Dynamic Range
USB DSD 106dB
USB PCM 112dB (24bit)
CD 100dB (16bit) -
Signal to Noise Ratio
USB DSD 112dB
USB PCM 112dB
CD 112dB -
Total Harmonic Distortion
USB DSD 0.0010%
USB PCM 0.0010% (24bit)
CD 0.0016% (16bit) -
Channel separation
USB DSD 110dB
USB PCM 110dB
CD 110dB
Algemeen
- Available colors: Black / Silver-Gold Yes / Yes
- Metal Front Panel Yes
- Remote Control RC003PMND
- Power Consumption in W 35
- Standby Consumption in W 0.3
- Auto Power off Yes
- Detachable Power Cable Yes
- Maximum Dimensions (W x D x H) in mm 442 x 424 x 130
- Weight in kg 10.3
- Carton Maximum Dimensions (W x D x H) in mm 527 x 517 x 255
- Carton Weight (inc. product) in kg 13.5
