Features
- CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC Yes / Yes / No / Yes / Yes / No
- CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data No / No / Yes / Yes / Yes
- Data Disc Compatibility: DSD / WAV / ALAC No / No / No
- DAC operation mode: USB B type / Coax / Optical No / No / No
- Asynchronous mode rear USB No
- Bit-perfect transmission No
- USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 No
- Signal isolator for DAC Mode operation No
- HDAM version HDAM+HDAM SA2
- Power Transformer: Toroidal / El No / Yes
- High Grade Audio Components Yes
- Customised Components Yes
- Symmetric circuit layout Yes
- Copper Plated Chassis No
- Extra metal plate for chassis strengthing Yes
- Digital out off / Audio EX Mode Yes / No
- Headphone: Standard / Buffer / Current feedback No / Yes (HDAM-SA2) / No
Others
- Selectable filter: CD / SA-CD / DAC-Mode Yes / No / No
- Marantz Musical Mastering Yes
- Marantz Musical Mastering Stream No
- Marantz Musical Mastering Conversion No
- Separated rectifier circuit for analogue and digital circuitry Yes
- Display: Dimmer / Off Yes / Yes
- Low noise LCD display No
- 5mm Aluminum top cover No
Playback
- Program Play (CD / SA-CD) 25
- Repeat Yes
- Random Play Yes
- Start Sound Mode for SA-CD No
Inputs Outputs
- Analogue Out (Cinch) 2ch
- Balanced Out No
- Digital Optical In / Out No / 1
- Digital Coaxial In / Out No / 1
- Sample Rate digital In No
- Gold Plated Cinch Yes
- USB Audio (Front) / Made for iPod / Made for iPhone® Yes / No / No
- USB-A: FLAC / WAV / AIFF / ALAC / DSD Yes
- USB type B input for PC (rear) Sample Rate USB type B In No
- Asynchronous mode rear USB No
- USB type B input for PC (rear) No
- USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 No
- D-Bus Yes
- Headphone Out Yes
- Headphone Volume Control Yes
Specifications
- Mechanism JTL-101Y
- D/A Conversion Multi-bit, Delta-Sigma
- Low Pass Filter stage HDAM
- Output Buffer HDAM SA2
- Headphone amp HDAM-SA2buffer+OPAMP
- Frequency Response (Cust.) No
- Dynamic Range (SA) No
- Signal to Noise Ratio (SA) No
- Total Harmonic Distortion (SA) No
- Channel Separation (SA) No
- Frequency response 2 Hz - 20 kHz
- Dynamic Range 100 dB
- Signal to Noise Ratio 110 dB
- Total Harmonic Distortion 0.00002
- Channel separation 98 dB
General
- Available Colors: Gold / Silver / Black / Silver-Gold No / No / Yes / Yes
- Metal Front Panel Yes
- Remote Control RC004PMCD
- Power Consumption in W 32
- Standby Consumption in W 0.3
- Auto Power off Yes
- Detachable Power Cable Yes
- Maximum Dimensions (W x D x H) in mm 440 x 340 x 105
- Weight in kg 6.5
- Carton Maximum Dimensions (W x D x H) in mm 517 x 468 x 189
- Carton Weight (inc. product) in kg 8.8
