Multichannel Surround
- DTS HD Master / DTS:X Yes / Yes
- DTS Neo:X / DTS Neural:X No / Yes (11ch)
- DTS Virtual:X Yes (update)
- Dolby TrueHD / Dolby Atmos Yes / Yes
- Dolby ProLogic Ilz / Dolby Surround No / Yes
- Auro 3D Yes
- Audyssey DSX No
- Multichannel Stereo Yes
- Max Number of Processing (Preamp) Channels 11.2
Sound Enhancements
- Discrete Power Amplifier Yes
- Copper Plated Chassis No
- Power Transformer: Toroidal / EI EI
- Current Feedback Topology Yes
- Hyper Dynamic Amplifier Modules (HDAM) Yes
- Pure Direct Yes
- High Grade Audio Components Yes
- Gold plated RCA terminals Yes
- Clock Jitter Reducer Yes
- Audyssey MultEQ XT32
- Audyssey Dynamic EQ / Dynamic Volume Yes / Yes
- Audyssey LFC Yes
- Compressed Audio Enhancer: MDAX2 Yes
Network
- HEOS Multi-room and Streaming Yes
- Network Audio Sharing Yes
- Lossy formats: MP3 / WMA / AAC Yes / Yes / Yes
- Lossless formats FLAC / ALAC / WAV Yes / Yes / Yes
- Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 Yes / Yes / Yes
- DSD Audio Streaming up to DSD5.6
- FLAC HD 192/24 Yes
- WAV 192/24 Yes
- ALAC 192/24 Yes
- Gapless Playback Yes (FLAC, WAV ,ALAC ,DSD)
- AirPlay Audio Streaming Yes
- AirPlay 2 Audio Streaming Yes
- Internet radio Yes (TuneIn)
- Spotify / Pandora / SiriusXM Yes / Yes / Yes
- Compatible with Remote APP for Smart Phones Marantz 2016 AVR Remote
- Compatible with Remote APP for Tablets Android / iOS / Amazon Kindle
- Ethernet Ports Yes
- Wi-Fi Yes
- Bluetooth Yes
HDMI
- HDMI Inputs: Back / Front 7 / 1
- HDCP2.2 Support Yes
- HDMI Outputs: Main / Zone 2 / 1
- Video Conversion Analog -> HDMI Yes
- Analog to HDMI Scaling 480i/576i up to 4K 60/50
- HDMI to HDMI Scaling up to 4K 60/50
- GUI Overlay on HDMI Yes
- HDMI: 3D / 4K / CEC / ARC / InstaPrevue Yes / Yes / Yes / Yes / No
- Enhanced ARC Yes
- HLG / Dolby Vision Yes / Yes
- 3D Signal Pass-Through Yes
- 4K Signal Pass-Through / Scaling / GUI Overlay Yes / Yes / Yes
- HDMI Pass-Through in Standby Mode Yes
- Picture Adjust / Noise Reduction Yes / Yes
- CEC Yes
- DSD Audio Capability Yes
- Audio Return Channel Yes
- Auto LipSync Yes
Multi-Room CI
- HEOS Multi-Room Integrated Yes
- HEOS Link Compatibility: IR/ IP Yes / Yes
- Multi-Room Zones 3
- Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Yes (2ch) / Yes (2ch) / Yes / Yes
- Zone Audio Output: Speaker / Preout Yes / Yes
- Zone HDMI Output from HDMI Source Yes
- IP Control / RS232 Control / Web Control / App Control Yes / Yes / No / Yes
- IR Flasher In Yes
- Marantz Remote Bus Yes
- DC Trigger Output 2
- HDMI Diagnostics Yes
Others
- Auto Speaker Setup by Microphone Audyssey MultEQ XT32
- FL Display 2 lines + port hole
- Graphic User Interface - GUI Advanced
- ISF Certification Yes
- GUI Languages 3
- Setup Assistant Yes
- Smart Select Yes
- Firmware Update by Network USB Yes / Yes
- Variable Cross Over Yes
- Optimized Bass Redirection Yes
- Bass Sync Yes
- ECO Mode Yes
- Auto Power off Yes
- Sleep Timer Yes
Inputs Outputs
- Composite In / Out 3+1 / 2
- Component In / Out 1 / 3
- HDMI In / Out 7+1 / 3
- Multi-Room Video Out: Video / HDMI Yes / Yes
- Analog In / Out 5+1 / No
- Phono (MM) In Yes
- Digital In: Optical / Coaxial 2 / 2
- Multi-Room Out: Analog / Digital 2 / No
- Multichannel Pre Out Yes (11.2)
- Subwoofer Out 2 (independant)
- 7.1 Multichannel Input Yes
- Speaker Terminal: Gold Plated Screw / Regular Screw Yes / No
- Number of Speaker Terminals 11
- Speaker A / B assignable
- Bi-Amp Drive assignable
- Multi-Room Speaker Terminal assignable
- Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB Yes / Yes / No / Yes / Yes
- USB Audio / Made for iPod / Made for iPhone Yes / No / No
- AM/FM Tuner Yes
Specifications
- Number of poweramps 9
- Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) 110 W
- Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) 125 W
- Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 165 W
- Power Output (6 ohm, 1 kHz, 10% 1ch Drive) 235 W
- 70% Guarantee Yes
General
- Metal Front Panel Yes
- System Remote Control RC036SR
- Pre-Programmed / Learnable / LCD Display Yes / No / No
- Power Consumption in W 710
- Power Consumption No-Sound (ECO on/off) in W 65 W / 110 W
- Standby Consumption in W 0.2
- CEC Standby Consumption in W 0.5
- Network Standby Consumption in W 2.7
- Network Control On Consumption in W (TBD)
-
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm
Antenna:Vertical :(W x D x H) in mm
W/o Antenna:(W x D x H) in mm 17.3 x 16.2 x 7.3
(17.3 x 16.2 x 9.7)
【 17.3 x 15.8 x 7.3 】 - Weight in lbs. 31.1
