Size & weight
- Net weight 8.42kg
-
Dimensions
Height: 345 mm cabinet only
Width: 192 mm cabinet only
Depth: 297 mm cabinet only
334 mm including grille and terminals
Technical details
-
Drive units
1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
1x ø165mm (6.5 in) Continuum cone bass / midrange - Frequency range 45Hz and 33kHz
- Frequency response 50Hz - 28kHz ±3dB
-
Harmonic distortion
2nd and 3rd harmonics (90dB, 1m on axis)
<1% 100Hz - 22kHz
<0.5% 150Hz - 20kHz - Nominal impedance 8Ω (minimum 3.7Ω)
- Recommended amplifier power 30W - 120W into 8Ω on unclipped programme
- Max recommended cable impedance 0.1Ω
- Sensitivity 88dB spl (2.83Vrms, 1m)
-
Technical features
Decoupled Carbon Dome tweeter
Continuum™ cone bass / midrange
Flowport™ - Description 2-way vented-box system
Finishes
-
Cabinet finishes
Gloss Black
Satin White
Mocha -
Grille finishes
Black
Grey (Satin White only)
