Size & weight
- Net weight 28.81kg
-
Dimensions
Height: 1010mm cabinet only
1117mm including tweeter and plinth
Width: 192mm cabinet only
290mm including plinth
Depth: 316mm cabinet only
353mm including grille and terminals
372mm including plinth
Technical details
-
Drive units
1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
1x ø150mm (6 in) Continuum cone FST midrange
2x ø165mm (6.5 in) Aerofoil Profile bass - Frequency range 30Hz - 33kHz
- Frequency response 46Hz - 28kHz ±3dB
-
Harmonic distortion
2nd and 3rd harmonics (90dB, 1m on axis)
<1% 90Hz - 22kHz
<0.5% 120Hz - 20kHz
- Nominal impedance 8Ω (minimum 3.1Ω)
- Recommended amplifier power 30W - 200W into 8Ω on unclipped programme
- Sensitivity 90dB spl (2.83Vrms, 1m)
-
Technical features
Decoupled Carbon Dome tweeter
Solid Body Tweeter-on-Top
Continuum™ cone FST™ midrange
Decoupled midrange
Aerofoil™ Profile bass cones
Flowport™ - Description 3-way vented-box system
- Max recommended cable impedance 0.1Ω
Finishes
-
Cabinet finishes
Gloss Black
Satin White
Mocha -
Grille finishes
Black
Grey (Satin White only)
