常规信息
- Unit (W x H x D mm) 442 x 129 x 396
- Net weight 7.5kg
- Packaging Dimensions (W x H x D mm) 525×249×511
- Panel Color Available Colors: Silver/Gold and Marantz Black
- Front (Center) Panel Aluminum
产品规格
-
频率响应
USB DSD: 2Hz - 50kHz (-3dB)
USB PCM: 2Hz - 50kHz (-1.5dB)
CD: 2Hz - 20kHz -
总谐波失真
USB DSD: 0.0006%
USB PCM 24bit: 0.0005%
CD: 0.0015% -
信噪比
USB DSD: 110dB
USB PCM 24bit: 118dB
CD: 118dB -
动态范围
USB DSD: 110dB
USB PCM 24bit: 118dB
CD: 101dB - Line Output Level 2.2Vrms
- 耳机输出put Level 28mW / 32 ohms
- Power Consumption 38W
- at Standby 0.3W
音频功能
- HDAM New HDAM + HDAM-SA2
- Power Transformer EI
-
耳机放大器
High slew rate op-amp
+ HDAM-SA2 - H/P Amp Gain Setting 是 (Low / Mid / High)
- 数字滤波器 Filter 1, 2 Selectable
连接播放能力
- CD Compatibility CD / CD-R/RW / WMA / MP3 / AAC
- Data Disc Compatibility DSD / WAV / ALAC
- Fixed Analog Output (RCA) 1 (Gold Plated)
- Optical input / output (Maximum Support) 0 / 1
- Coaxial input / output (Maximum Support) 0 / 1
- 耳机输出put 1
-
远程控制 Bus Terminal
是 (RC-5 In / Out)
w/ External / Internal Select Switch -
USB A
1 (Front)
Mass Storage Class
5V/1A - Support format FAT 16/32
- USB-A: FLAC / WAV / AIFF / ALAC / DSD 是 / 是 / 是 / 是
- DSD Native 播放 是
- USB Firmware Update 是
使用便捷
-
远程控制ler
System Remote
(Amp and CD Player Control) - Unit control (Button) POWER, Play/Pause, Stop, Input, Open/Close, Fwd, Rev
-
Unit control (Knob)
1
Phones Level - Dimmer for 正面显示 Bright / Dim / Dark / Off
- Control with App via Network Player (Use 远程控制 Bus) 是
- Last Function Memory 是
-
Timer Play (Need external audio timer)
是
On/Off selectable in Menu - Auto Standby Mode 是
-
Other
Stereo RCA Cable x1
Remote connector cable x1 - Accessory Box 是
- Battery 是 (AAA x2)
- Power Cord 是
